Ammann ARR 1575 - Description of Basic Elements

32 ARR1575
555007B
1
2
3
4
5
6
555008B
7
8
9
10
11
5 Frame
Right side view
1 - One-point lifting lug
2 - Name plate
3 - Drum scraper
4 - Rear bonnet lock
5 - Front bonnet lock
6 - Front infrared sensor
Left side view
7 - Articulation joint lock
8 - Safety bar (optional)
9 - Control panel cover
10 - Rear infrared sensor
11 - Light indication
5.1 Description of basic elements
