7 Front drum
7.4.3 Disassembly of the vibration unit
View of the vibration housing after opening.
The grease in the housing is consumed after a certain
number of operating hours and must be relled.
The following steps were performed on anew vibration unit.
The grease is therefore unconsumed and light in all pictures.
Clean the vibration housing, remove the consumed grease.
Remove the screws on the bearing cap.
