Ammann ARR 1575 - Checking the Steering Pressure

299ARR1575
557D018
1
557D019
WORKSHOP MANUAL
18.2.2 Checking the steering pressure
Turn the machine to the limit position.
Hold the lever pressed throughout the entire further procedure.
Measurement point (1) Vibration/steering pressure.
If asteering pressure of 67 ± 7 bar is not reached:
• remove the right steering piston line and pressure-close it.
• remove the left steering piston line and pressure-close it.
• remove the valve block, see “Replacement of the valve
block” (Chapter 11.2.2).
• check the steering pressure relief valve.
