WORKSHOP MANUAL

18.2.7.1 Checking the travel pump magnetic coil

/ travel pump servo block

The travel pump magnetic coil cannot be controlled mechani-

cally.

Loosen the knurled nut.

Remove the magnetic coil.

Screw out the magnetic valve.
