15 Engine
15.4.3 Checking the engine oil level
Oil dipstick
Check the engine oil level daily using the oil dipstick. The oil dip-
stick (1) is located on the left side of the engine.
Check it at ahorizontal position of the roller and with cold en-
gine.
The engine oil level can be seen on the oil dipstick. The oil level
must be between the upper mark (x) and the lower mark (y).
Rell the engine oil as required.
15.4.4 Engine oil replenishment
Replenish the engine oil through one of the two ller necks.
Filler neck on the left side of the engine.
Filler neck on the engine.
Filler neck on the left and ller neck on the top.
To assure permanent operational safety of the engine,
no additives may be added to the engine oil.
15.4.5 Engine oil draining
The engine oil drain (1) is located under the chassis, front left.
Operating uids pose arisk to the environment!
Prevent uids from leaking into sewage systems, soil or
the environment.
Place avessel under the drain.
Remove the drain plug.
The oil ows out immediately.
