Ammann ARR 1575 - Dimensional Drawing of the Machine

22 ARR1575
D
B
C
E
F
G
I
J
A
H
555003
3 Machine description
3.2 Dimensional drawing of the machine
mm
(in)
A B C D E F G H I J
ARR 1575 T4 nal
640
601 302 36 640 2227 1980 1000 525 1282 1317
(23.7) (11.9) (1.4) (25.2) (87.7) (78.0) (39.4) (20.7) (50.5) (51.9)
850
601 407 36 850 2227 1980 1000 525 1282 1317
(23.7) (16.0) (1.4) (33.5) (87.7) (78.0) (39.4) (20.7) (50.5) (51.9)
