70 ARR1575

557D577

557D578

557D579

557D580

5 Frame

Remove the bearing lock screw.

Cut the thread in the support chassis.

Mount the screws.

In the event of corroded bearing seat, use 4 screws.

Remove the bearing lock (1).
