71ARR1575
1
2
WORKSHOP MANUAL
Screw in the screws until the swivel bearing from the bearing
pin.
Because there is not enough space for longer screws than
M12x100, spacers (approx. 20 mm) must be placed under the
screws.
Remove the screws as soon as the bearing is pushed out of the
bearing pin.
Use squared wood (1) to separate the chassis at the front and
back.
Use another squared wood (2) to support the chassis at the back.
Special tool for the removal of the articulated bearing.
