163ARR1575

557D301

557D302

557D303

557D304

WORKSHOP MANUAL

Clean / blow-clean the boreholes in the gearbox cover.

Clean the sealing surface of the gearbox cover.

Apply blue adhesive on the threads of the rubber elements.
