Ammann ARR 1575 - Page 167

To Next Page

To Previous Page

165ARR1575

557D309

557D310

557D308

WORKSHOP MANUAL

Install the hose guide holder (1) using the same screws.

Tighten the screws (1) to atorque of 36Nm.
