174 ARR1575

557D396

557D397

557D398

557D399

7 Front drum

Apply blue adhesive on the screws.

Mount the travel hydraulic motor using the screws. The tighten-

ing torque is 85 Nm.

Remove the aid.

Mount all hoses.
