WORKSHOP MANUAL
Mount the hydraulic hose of the T-screw union (BR).
To maintain access to the screw union of the B1 hose (1), rst
move the magnetic coil (2) back.
Remove the knurled nut.
Remove the sealing ring.
Move the magnetic coil (2) back.
Mount the B1 hydraulic hose (1).
Move the magnetic hose back to the initial position.
Mount the sealing ring (1).
Mount the knurled nut.
Firmly tighten the magnetic coil.
