Ammann ARR 1575

To Next Page

To Previous Page

48 ARR1575

557D188

557D189

557D190

557D191

5 Frame

Remove the rubber-metal element from the holder.

Apply blue adhesive on the rubber-metal element screw.

Mount the rubber-metal element into the holder.
