Amsco Evolution HC-600 - Figure 10-2. Door Seal Replacement, 660 X 950 MM (26 X 37.5) Sterilizers

10-5
Service Procedures Operator Manual P129390-106
Figure 10-2. Door Seal Replacement, 660 x 950 mm (26 x 37.5”) Sterilizers
Use flat tool with
rounded edges
(such as a non-
serrated table
knife) to pry and
twist one section of
the seal partially
from the groove.
Hinged Door Model Shown
Seal
Door
Chamber
Opening
The following lot data is molded into the back side of
the seal:
Location
of Seal
Reference
Indicators
Back Side
of Door Seal
Reference Indicator,
Enlarged
P-129373-376 ABCDEFHGIJKLMNOP 1234 07 P
Part Number Lot Index Cure Year Manufacturer
Quarter Code
The lot index and cure quarter are struck off during manufacturing.
The first characters in sequence
not struck are those used for
identification. For example:
ABCDEFHGIJKLMNOP 1234 07 P
The cure date is: 3rd Quarter, 2007. The lot is: 02C.
