9-15

Troubleshooting Operator Manual P129390-106

9.3.8 UPS Battery

Low

Battery power for

uninterruptibile power

supply has dropped below

a level capable of

powering the seriliser

control in the event of

power failure.

Alarm Screen UPS battery or UPS may be

malfunctioning.

Causes and Correction:

1. Battery failure

• Replace

2. Loose wiring

•Repair

Table 9-2. Operator Troubleshooting – Out-of--Cycle Alarms (Continued)

Condition Alarm Screen on Sterilizer Control Service Information
