TIP: Use the CLEAR button (located at the bottom of the screen toolbar) to clear the selection (display no input and output
to the screen background color).
To load a preset:
Front Panel
1. Enter the PRESETS menu on the Front Panel interface.
2. Select Load Preset to access the preset memories bank.
3. Select a bank slot to recall the preset memory contained in the selected slot.
Web RCS
1. Go to the Edit menu on the Web RCS interface.
2. Select the SCREEN tab to access the screen edit page.
3. In the right side toolbar, select Preset to access the preset memories bank.
4. Click on a bank slot to recall the preset memory contained in the selected slot.
TIP:
• Hover over a slot to have an overview of the preset memory contained in the slot.
• SHIFT+click on a slot to freeze the preset Memories Overview box and label the preset memory contained
in the slot.
• Use the Show memories label button to show preset labels directly on the view bank slots.
