USER MANUAL
Web RCS
1. Go to the Setup menu on the Web RCS interface.
2. Click on the AUDIO tab to access the audio management page.
3. In the left side toolbar, select the XLR Card tab to access the XLR audio inputs and outputs setup page.
4. Under the XLR card section (right-side window), select the XLR Output Mode.
Available XLR output modes include:
NONE
No output
DIGITAL
Digital double AES
ANALOG BALANCED
Analog stereo balanced
5. If required, select the XLR Output Pair 1.
6. If required, select the XLR Output Pair 2.
Related topics:
• Expansion interfaces
