USER MANUAL
Available digital input modes include:
AES3
Digital mode AES
S/PDIF
Digital mode SPDIF
To adjust the XLR audio output settings:
NOTE: AES3 is the only supported Digital output.
Front Panel
1. Enter the AUDIO menu on the Front Panel interface.
2. Scroll down and select Option Card Settings to access the audio optional card settings.
3. Select XLR Out Mode to choose the XLR card output mode.
Available XLR output modes include:
NONE
No output
DIGITAL
Digital double AES
ANALOG BALANCED
Analog stereo balanced
4. If required, select the XLR Output Pair 1.
5. If required, select the XLR Output Pair 2.
