• V Back Porch: Set the vertical back porch (frame 0) (in pixels).
• V Sync: Set the synchro vertical size (in pixels).
• V Positive Polarity: Enable the synchro vertical polarity.
TIP:
• Select Load from Template to load the parameter values of a predefined output format.
• Select Load from Custom Format Bank to load the parameter values of an already created custom format.
• Use Reset to reset all custom format parameters to their default (edit mode) value.
5. Once you have finished editing the custom format parameters, select Check to check that the new
custom format settings are valid.
Check result information may include:
• (ERROR STATUS): (Only if format is not valid) Format error status.
List of possible format error status:
• H Total: Number of pixel in a line (in pixels).
• V Total: Number of lines in a frame (in pixels).
• Pixel Frequency: Signal pixel frequency (in Hz).
• Line Frequency: Signal line frequency (in kHz).
6. If the custom format is valid, select Save as to save the new custom format settings
NOTE: You will be asked to select a custom format bank slot to save your custom format:
• Available (empty) bank slots will appear in black.
• Not available (occupied) bank slots will appear in blue.
7. Select a bank slot to contain the format and press the ENTER key to confirm (or use the EXIT-MENU
key to go back to edit mode without saving the format)
Web RCS
1. Go to the Setup menu on the Web RCS interface.
2. Click on the OUTPUTS tab to access the outputs setup page.
3. In the left side toolbar, select Custom Formats to access the custom formats page.
4. In the SLOT #1-64 window, select a custom format bank slot to contain your format.
TIP:
• Select an empty bank slot to create a new custom format.
• Select a non-empty bank slot to edit the custom format contained in the selected slot.
5. In the right side window, click on the Edit button to access the custom format parameters in edit
mode.
6. Select a Mode to edit the custom format parameters:
To Next Page
