Web RCS

1. Go to the Setup menu on the Web RCS interface.

2. Click on the CONTROL tab to access the device settings and control functions.

3. In the left side toolbar, select Front Panel to access the front panel settings page.

4. Under Key Brightness, click and drag the key brightness control bar right or left to adjust the

brightness of the front panel key buttons.

To lock the front panel key buttons:

Front Panel

1. Enter the CONTROL menu on the Front Panel interface.

2. Scroll down and select Front Panel to access the front panel settings menu.

3. Select Front panel locking to change the front panel key locking mode.

List of possible front panel key locking modes:

NONE

Lock no front panel button (all enabled front panel key buttons will

be available)

ONLY MENUS

Lock the front panel navigation buttons only (INPUT SELECTION

buttons and SHORTCUT buttons will remain available)

MENUS + KEYBOARD

Lock all the front panel buttons (no key button will be available)

TIP: In the front panel settings menu, check the Safe Input Select check-box to disable the selection of inputs

for which no valid signal has been detected.

Web RCS

1. Go to the Setup menu on the Web RCS interface.

2. Click on the CONTROL tab to access the device settings and control functions.

3. In the left side toolbar, select Front Panel to access the front panel settings page.

4. Under Lock, select a front panel key locking mode.
