To automatically fit the AOI to the output format:
Front Panel
1. Enter the OUTPUTS menu on the Front Panel interface.
2. Select STANDARD OUTPUT to access the standard output setup menu.
3. Select Area of Interest to access the AOI setup menu.
4. Check the Fit Format Resolution check-box to automatically fit the AOI to the output format.
5. If required, adjust the Overscan Compensation (as percentage of the output format size).
Web RCS
1. Go to the Setup menu on the Web RCS interface.
2. Click on the PRECONFIG tab to access the setup assistant.
3. If the Screens page is active, click on the Previous button to access the area of interest setup page.
4. Check the Fit to Output's Active Area check-box to automatically fit the AOI to the output format.
