Only one port is able to allow In-band control. When In-band control is allowed at
another port, this setting cannot be made.
When Port Setup is set to 10Gbps WAN10Gbps WAN, In-band control is not performed.
This tab is not displayed in the Cable, Pass Through, and Discovery applications.
For the Discovery application, In-band control is allowed internally and the remote
control via test interface is enabled.
For the Reflector application, selecting Allow In-band controlAllow In-band control selects the following
settings in the Swap forcibly.
Swap IP address
Swap UDP/TCP ports
Src. MACSrc. MAC
Set a MAC address of the port used for the In-band control communication.
Selecting DefaultDefault check box uses the MAC address assigned to the port
hardware.
Do not set the following MAC addresses. It is unable to search for Network Masters
using one of these addresses in the Discovery application.
Multicast MAC address (including FF-FF-FF-FF-FF-FF)
00-00-00-00-00-00
Src. IPSrc. IP
Set an IP address of the port used for the In-band control communication.
Selecting DHCPDHCP obtains an IP address automatically. Following setting values
are fixed.
DSCP/TOS: 0x00
TTL: 20
The DHCPDHCP is available when the interface bit rate is 100 Gbps or less.
Do not set the same address for Src. IPSrc. IP of Discovery application one in the application
which is searched for.
The following addresses cannot be set.
The same IP address as the IP address set at Ethernet in the Network screen on
Instruments tool bar
Address whose first one byte value is 0 or 224 to 225
Loopback address (129.0.0.1)
Network address (all bits in host part are set to '0')
Broadcast address (all bits in host part are set to '1')
Network maskNetwork mask
Set a network mask for In-band control.
Set a network mask and IP address so that the network does not duplicate with one
specified in Ethernet in NetworkNetwork screen on Instruments tool bar.
GatewayGateway
Selecting check box allows users to set the default gateway IP address.
PasswordPassword
When the check box is selected, a password with 4 to 8 characters can be set.
VLAN LevelVLAN Level
When VLAN is set to the In-band control communication, set LevelLevel and IDID.
Following setting values are fixed.
