G0325A
MU100090A (When using J1706A GPS antenna of the standard accessory)
When using the following GNSS antenna provided by Anritsu, set 40 ns.
MU100090B (When using J1886A GNSS antenna of the standard accessory)
Sync intervalSync interval
Allows you to specify the interval between transmitted sync messages.
Available values are between 1/128 s1/128 s and 32 s32 s.
The data to send actually is displayed in hexadecimal.
Min delay Req. intervalMin delay Req. interval
Allows you to specify the minimum interval between transmitted delay request
messages. Available values are between 1/128 s1/128 s and 32 s32 s.
The data to send actually is displayed in hexadecimal.
Unicast durationUnicast duration
In unicast slave mode, you ask a master to emit announce, sync and delay
response messages for some time. This setting is enabled when the Setup tab is
set to either of the following.
Profile is set to G.8265.1G.8265.1 and Slave modeSlave mode is selected.
Profile is set to User DefinedUser Defined and Slave modeSlave mode, UnicastUnicast, Unicast negotiateUnicast negotiate are
selected.
After this period, the master forgets everything about your request. The Unicast
duration is this period in seconds. Legal values are from 60 to 1000 seconds. A
Network Master unicast slave will renew the request 10 seconds before
timeout.
Advanced tabAdvanced tab
On the AdvancedAdvanced tab, you can edit the flag field of the announce message if the
Slave modeSlave mode check box is not selected on the Setup tab.
flagFieldflagField
Displays the bit settings of Octet:0 and Octet:1 in hexadecimal.
