VLAN layerVLAN layer
When the VLAN level count is 2, the two VLAN levels will be designated S-
VLAN and C-VLAN. S-VLAN is short for Service provider VLAN and C-VLAN is
short for Customer VLAN.
Level countLevel count Up to eight levels of VLAN can be inserted in the frame. The
number of VLAN fields is selected through the Level countLevel count drop-down menu,
and each level is set up individually.
IDID Touching the IDID (VLAN ID) button launches a setup dialog box from which it
is possible to set up a denoting of the virtual LAN.
DEIDEI Selecting the DEIDEI check box sets a 1-bit flag denoting whether MAC
addresses inside the frame are in canonical format.
PriorityPriority It is possible to set up the priority level of each frame.
EthertypeEthertype When the Level count is more than one, select the type from 0x81000x8100,
0x88A80x88A8, 0x91000x9100 or 0x92000x9200.
The layer 3 protocol number is displayed in the lowest line.
IPv4 layerIPv4 layer
IGMP hostIGMP host and IGMP versionIGMP version appear when Profile is set to SMPTE 2059-1SMPTE 2059-1.
Src IPSrc IP - Input the IPv4 source address.
Dst IPDst IP - In unicast mode, input the IPv4 destination address.
DSCP(PTP events message)DSCP(PTP events message) and DSCP(PTP other message)DSCP(PTP other message) - Set the DSCP
value to be used for transmitted PTP event frames and a value for all other
PTP frames. Acceptable values are between 0x00 and 0x3F.
IGMP hostIGMP host - Touch JoinJoin to send a Join message from the Network Master to
the IGMP host. The button display changes to LeaveLeave.
Touch LeaveLeave to send a Leave message to the IGMP host.
IGMP versionIGMP version - Select a version from the list. Refer to IGMP host of Stream
setup.
IPv6 layerIPv6 layer
MLD hostMLD host and MLD versionMLD version appear when Profile is set to SMPTE 2059-1SMPTE 2059-1.
Src IPSrc IP - Select setting mode using drop-down menu.
ManualManual: touch the field to enter 32 Hex values.
StatelessStateless: configures the address automatically. The lamp lit in green if
the automatic configuration has succeeded.
Touching the SetupSetup button under the virtual lamp in the Src IPSrc IP
line will open the Stateless IPv6 SetupStateless IPv6 Setup dialog box.
Selecting the Use src MACUse src MAC check box configures the interface ID
from the MAC address.
When the check box is clear, touch the field to set the interface
ID.
Touching Renew nowRenew now starts the source IP address configuration.
Dst IPDst IP - In unicast mode type in the IPv6 destination address.
Multicast scopeMulticast scope - Select one of the predefined IPv6 multicast scope values or
choose User definedUser defined to manually enter a value. Acceptable values are
between 0x0 and 0xF.
Payload lengthPayload length - Select how to set the payload length.
AutoAuto: Payload length in the IPv6 header is set automatically.
NullNull: Sets 0 to the payload length in the IPv6 header.
