Only available if you have specified a Throughput and Frame LossThroughput and Frame Loss test on the
ControlControl screen. Use this test if you want to perform both a Throughput test and
a Frame Loss test while using the same test parameters for both.
Touching the Throughput and frame lossThroughput and frame loss button in the navigation area will
launch the screen shown below.
This screen allows you to configure the following parameters related to an RFC
2544 Throughput and Frame Loss test:
Frame Size
Duration
Line Load
Throughput Calculation Layer Selection
Threshold
The settings for 'Throughput and Frame Loss' are identical to the ones
described in the Throughput section above.
Note that under ThresholdThreshold, the Throughput frame loss toleranceThroughput frame loss tolerance check box is
not displayed for a Throughput and Frame Loss test.
66..99..22..55 Latency/JitterLatency/Jitter
Only available if you have specified a Latency/JitterLatency/Jitter test on the ControlControl screen.
Touching the Latency/JitterLatency/Jitter button in the navigation area will display the
screen shown below.
