Chapter 4 Window Operations
4-32.
Figure 4.10.2-3 Combination Setting dialog box
Table 4.10.2-1 Screen Layout of Combination Setting
Operation setting items Description
Operates each channel of MU183040A/B or
MU183041A/B independently.
Synchronizes two channels of MU183040A/B-x20
or MU183041A/B.
Synchronizes four channels of MU183041A/B.
To confirm the operation settings you made, click
.
By selecting
, buttons to select channels are displayed in the
ED window.
