Appendix E Sequence Examples
E-18.
E.6 Use Example of Status Command
This section describes an example procedure for executing PPG-MUX
Adjustment and loading status using remote commands.
Table E.6-1 Use Example of Status Command
Remote Commands Explanation of Commands
:USB:ID 7;:DISP:ACT 0,7,1
:INST:MUX:RES
:INST:MUX:PTR 32
:INST:MUX:NTR 0
:INST:MUX:EVEN?
:SYST:INP:DCAD
:INST:MUX:EVEN?
:INST:MUX:COND?
Sets the remote command destination to MUX.
Initializes the status register.
Sets the positive logic Transition. Set to 32 (bit 5)
here to determine the Adjustment state between
PPG-MUX.
Sets the negative logic Transition. Set to 0 here,
as negative logic is not checked.
Clears Event with one query.
Starts PPG-MUX Adjustment.
Determines that Adjustment has started.
Querying continues until the return value is
"32".*
Determines that Adjustment has ended.
Querying continues until the return value is "0".*
*: Use processing corresponding to C language "for" and "While"
statements for this processing to send queries until the expected
value is detected. Set the sending interval between queries to at
least 200 ms to avoid overloading the instrument used for the
measurement processing. Execute the next command after the
expected value has been detected.
