E.3 Setting Examples of Measurement Conditions
E-9
App
endix
A
ppendix E
E.3.5 Setting example of Test Conditions - Data Output ON -
This section describes the procedure for setting the MUX Data Output to
ON.
Table E.3.5-1 Setting example of MP1861A Data Output ON
Remote Commands Explanation of Commands
:USB:ID 7
:MUX:DATA:OUTP ON
:SOUR:OUTP:ASET ON
Wait 6000 ms.
*
2
:SYST:INP:DCAD:AUTO ON
Sets the remote command destination to MUX.
Enables the MUX Data Output.
Enables Data Output for the entire system.
The phase of the Data and Clock input to the MUX
is automatically adjusted after initialization.
About six seconds are required until completion.*
1
Enables the function to automatically adjust the
phase of the Data and Clock input to the MUX.*
2
*1: Wait- indicates the recommended wait time for sending the
command. This command is not supported by the MP1800A.
*2: To specify the timing for executing phase adjustment of the Data
and Clock input to the MUX, set to OFF. If set to OFF, the Wait
processing unit can be replaced using the procedure described in
"E.6 Use Example of Status Command".
