1.3 Specifications
1-5
1
Overview
1.3 Specifications
1.3.1 Specifications for MP1862A
Table 1.3.1-1 Specifications for MP1862A
Item Specifications Remarks
Operating Bit Rate 8 to 56.2 Gbit/s
8 to 64.2 Gbit/s (when MP1862A-x01 installed)
External
Clock Input
Number of Input 1 (Ext. Clock Input) To input a
half-rate clock
from the Clock
Output1
connector of
MP1861A.
Frequency 4 to 28.1 GHz
4 to 32.1 GHz (when MP1862A-x01 installed)
Amplitude 0.3 to 1.0 Vp-p
Termination 50

AC
Connector K (f.)
Data
Output
Number of
Output
2 (Data Output 1, Data Output 2) To
MU18304xA/B
Data Input
Level 0/–0.4 V
H: –0.1 to +0.1 V
L: –0.6 to –0.3V
Termination 50

/GND
Connector K (f.)
1/2 Clock
Output
Number of
Output
1 (1/2 Clock Output) To output to the
Clock Input
connector of
MU18304xA/B.
Output
frequency: Half
of the frequency
input to the Ext
Clk Input
connector.
Frequency 2 to 14.05 GHz
2 to 16.05 GHz (when MP1862A-x01 installed)
Amplitude 0.3 to 1.0 Vp-p
Termination 50

AC
Connector SMA (f.)
Clock
Output
Number of
Output
1 (Clock Output) To be
terminated into
50

when not
in use.
Output
frequency: The
same as the
frequency input
to the Ext Clk
Input
connector.
Frequency 4 to 28.1 GHz
4 to 32.1 GHz (when MP1862A-x01 installed)
Amplitude 0.4 to 1.0 Vp-p
Termination 50

AC
Connector K (f.)
