Table 1.3.1-1 Specifications for MP1862A (Cont’d)
Item Specifications Remarks
Buffered
Clock
Output
Number of Output 1 (Buffered Clock Output) To be
terminated into
50

when not
in use.
Output
frequency: The
same as the
frequency input
to the Ext Clk
Input
connector.
Frequency 4 to 28.1 GHz
4 to 32.1 GHz (when MP1862A-x01 installed)
Amplitude 0.2 to 1.0 Vp-p
Termination 50

AC
Connector K (f.)
Delayed
Clock
Output
Number of Output 1 (Delayed Clock Output) To output the
clock having the
1x, 2x or 4x
frequency of the
clock input to
the External
Clock Input
connector.
Frequency 4 to 28.1 GHz
4 to 32.1 GHz (when MP1862A-x01 installed)
Amplitude 0.2 to 1.0 Vp-p
Termination 50

AC
Connector K (f.)
Demux
Clock Input
Number of Input 1 (Demux Clock Input) To be connected
to the Delayed
Clock Output
connector.
To output the
clock having the
1x, 2x or 4x
frequency of the
clock input to
the External
Clock Input
connector.
Frequency 4 to 28.1 GHz
4 to 32.1 GHz (when MP1862A-x01 installed)
Amplitude 0.2 to 1.0 Vp-p
Termination 50

AC
Connector K (f.)
