6.2 Devices Required for Performance Tests
6-3
6
Performance Test
6.2 Devices Required for Performance Tests
Before starting performance tests, warm up the MP1862A and the
measuring instruments for at least 30 minutes. Table 6.2-1 shows the
devices required for performance tests.
Table 6.2-1 Devices Required for Performance Test
Device Name Required Performance
Pulse Pattern Generator + MUX
(MP1800A-015/016
+ MU183020A-x22/x23, x31
+ MU181000A/B)
MUX (MP1861A)
Error Detector
(MU183040A/B-x20)
Operating frequency: 8 to 56.2 GHz
Data clock phase variable: 2 UI or more
Pulse Pattern Generator + MUX
(MP1800A-015/016
+ MU183020A-x01, x22/x23, x31
+ MU181000A/B)
MUX (MP1861A-x01)
Error Detector
(MU183040A/B-x01, x20)
Operating frequency: 8 to 64.2 GHz
Data clock phase variable: 2 UI or more
Sampling Oscilloscope
70 GHz or more band
Note:
Before starting the performance tests, warm up the device under
test and the measuring instruments for at least 30 minutes and
wait until they become sufficiently stabilized, unless otherwise
specified. Additional conditions are required for maximum
measurement accuracy: measurements must be performed at room
temperature, fluctuations of AC power supply voltage must be
small, and noise, vibration, dust, and humidity must be
insignificant.
