2.1 Preparation Before Use
2-3
2
2.1.3 Power Connection
This section describes the procedures for supplying power.
Use a supplied AC adapter. If AC adapter other than the supplied one is
used, the MP1862A may be damaged.
Connect the shielded connector from the AC adapter to the rear panel
connector of the MP1862A. Refer to Figure 2.1.3-1.
Figure 2.1.3-1 Rear Panel of MP1862A
Insert the power plug into an outlet, and connect the other end to the
power inlet on the rear panel. To ensure that the instrument is earthed,
always use the supplied 3-pin power cord, and insert the plug into an
outlet with an earth terminal.
WARNING
If the power cord is connected without grounding
MP1862A, there is a risk of receiving a fatal electric shock.
In addition, the peripheral devices connected to MP1862A
may be damaged.
When connecting to the power supply, DO NOT connect to
an outlet without a ground terminal. Also, avoid using
electrical equipment such as an extension cord or a
transformer.
