4.3 Displaying Measurement Results
4-5
4
Window Operations
4.3 Displaying Measurement Results
To display the measurement results, click the
Result
tab on the operation
window. The
Result
tab consists of the setting area (upper) and the result
display area (lower). You can view the measurement results while
checking the setting items of the MP1862A.
Figure 4.3-1 Result Tab
In the setting area, you can view the settings configured on the
Interface
tab.
Setting Area
Result
Display Area
