Appendix E Sequence Examples
E-8
30 Gbps < Bitrate
≤
60 Gbps Quarter Clock Rate(QUAT)
Bitrate
≤
30 Gbps Half Clock Rate(HALF)
Send the following remote commands when the MU181500B (Jitter
Module) is not installed.
Table E.3.4-2 Jitter Input examples with MU181500B not installed
Remote Commands Explanation of Commands
:USB:ID 7
:MUX:DATA:JINP OFF
:USB:ID 11
:DEM:CLOC:JINP OFF
:DEM:CLOC:BAND HALF
Sets the remote command destination to MUX.
Sets MUX Jitter Input to OFF.*
1
Sets the remote command destination to DEMUX.
Sets DEMUX Jitter Input to OFF.*
1
Sets DEMUX Clock Input to Half Rate.
The DEMUX Ext Clk Input and MUX Clk Output
(or equivalent signal) must be connected using a
coaxial cable.
Send the following remote commands for MX181500A Jitter Application
measurement.
MX181500A Jitter Application is launched after this command is sent.
For example command sequences and how to start MX181500A, refer to
the MX181500A Operation Manual.
Table E.3.4-3 Jitter Input examples for MX181500A Jitter Application Measurement
Remote Commands Explanation of Commands
:USB:ID 7
:MUX:DATA:JINP ON
:USB:ID 11
:DEM:CLOC:JINP ON
:DEM:CLOC:BAND HALF
Sets the remote command destination to MUX.
Sets MUX Jitter Input to ON.
Sets the remote command destination to DEMUX.
Sets DEMUX Jitter Input to ON.
Sets DEMUX Clock Input to Half Rate.
The DEMUX Ext Clk Input and MUX Clk Output
(or equivalent signal) must be connected using a
coaxial cable.
