7.4 Automatic Measurement Commands
7-85
7
Remote Commands
:SYSTem:MMEMory:DIAGram:STORe
<file_name>,<data_type>,<file_type>
Parameter <file_name>=<STRING PROGRAM DATA>
"<drv>:\[<dir>]<file>"
<drv> = C,D,E,F
<dir>=<dir1>\<dir2>\...(Omitted for the root directory)
<file> = File Name
<data_type>=<CHARACTER PROGRAM DATA>
EDG Eye Diagram Result
UMP Eye Mask Template File
<file_type>=<CHARACTER PROGRAM DATA>
BIN Binary file
CSV CSV file
TXT Text file
When BIN is selected for <file_type>, the Eye Diagram measurement
settings and results are saved, regardless of the setting of <data_type>.
When UMP is selected for <data_type>, select TXT for <file_type>.
Function Saves the Eye Diagram measurement result data.
Note:
The settings will not be read from the saved file if the file name is
changed.
Example To save the Eye Mask Detail measurement results of the Eye Diagram
measurement, by specifying the file format, file name, and save destination:
> :SYSTem:MMEMory:DIAGram:STORe "C:\Test\example",EDG,TXT
