Appendix C Performance Test Record Sheet
C-2.
Table C.1-1 Interface range
MP1861A MP1862A Results
No. Termination
Amplitude
[Vp-p]
Offset (Vth)
[V]
Termination Threshold voltage [V]
1 GND 1.0 –2.500 GND –2.500
2 0.25 –1.127 –1.127
3 0.25 +1.528 +1.528
4 1.0 +2.800 +2.800
Table C.1-2 Test pattern
Option Configuration Specification Results
PRBS, 2^n–1 =
7, 9, 10, 11, 15, 20, 23, 31), Mark ratio: 1/2
No error
Zero Substitution, Length: 2^n–1, n = 7, 9, 10, 11,
15, 20, 23 or 2n, n = 7, 9, 10, 11, 15, 20, 23
No error
Table C.1-3 Error detection
Option Configuration Specification Results
Error rate (ER) 1.0000E–11
Error count (EC) 1.0000E–00
Error free interval (EFI) 99.9900%
Error interval (EI) 1
Clock frequency (Frequency) 999500 to 1005000 kHz
