Chapter 3 Panel Layout and Connectors
3-4
Table 3.1.2-1 MP1862A Rear Panel Name and Function (Cont’d)
No. Name Description
[8] Channel Setting switch Sets the channel number of MP1862A.
Make sure the power to MP1862A has been shut off before
changing the channel switch settings. The new channel number
setting is enabled when powering on the next time.
[9] Frame ground Connector for wrist strap to discharge static electricity
Always wear a wrist strap when using this equipment.
Channel Number Switch Setting
1 0,0,0
2 1,0,0
3 0,1,0
4 1,1,0
