Chapter 3 Panel Layout and Connectors
3-6
CAUTION
Avoid inputting the signal exceeding the maximum input
level of MP1862A when connecting the Data Output
connector of MP1861A to the Data Input1 and 2 connectors
of MP1862A.
Maximum input level of the Data Input1 and 2 connectors
of MP1862A: 1.00 V
Maximum data output level:
MP1861A-x13: 3.50 Vp-p
MP1861A-x11: 2.50 Vp-p
The Data Input connector of MP1862A can be damaged if
the signal exceeding the maximum input level is input.
