Chapter 3 Panel Layout and Connectors
3-8
[Procedure]
1. Connect the Clock Output connector of MU181000A and the Ext.
Clock Input connector of MU181500B by using the J1624A coaxial
cable that comes with MU181000A.
2. Connect the Jittered Clock Output connector of MU181500B and the
Ext. Clock Input connector of MU183020A by using the J1624A
coaxial cable that comes with MU181500B.
3. Connect the Data Input1/2 connectors on the rear panel of MP1861A
and the Data Output1/2 connectors of MU183020A respectively by
using coaxial cables. The coaxial cables must be one of the following:
• J1658A coaxial skew match pair cable that comes with MP1861A
• Coaxial cables that are of the same length
4. Connect the Clock Output connector of MU183020A and the Ext.
Clock Input connector on the rear panel of MP1861A by using the
J1652A coaxial cable that comes with MP1861A.
5. Connect the Delayed Clock Output and MUX Clock Input connectors
on the rear panel of MP1861A by using the J1654A cable that comes
with MP1862A.
6. Connect the Data Output and
Data
Output connectors on the front
panel of MP1861A to the DUT by using coaxial cables.
7. Connect the Clock Output connector on the front panel of MP1861A
and the Ext. Clock Input connector on the front panel of MP1862A by
using a coaxial cable. On the Interface tab of MP1862A, click Half
Rate in the Clock Input Band box.
8. Connect the DUT and the Data Input and
Data
Input connectors on
the front panel of MP1862A by using coaxial cables.
9. Connect the Delayed Clock Output and DEMUX Clock Input
connectors on the rear panel of MP1862A by using the J1654A cable
that comes with MP1862A.
10. Connect the Data Output1/2 connectors on the rear panel of
MP1862A and the Data Input1/2 connectors of MU183040B
respectively by using coaxial cables. The coaxial cables must be one
of the following:
• J1657A coaxial cables that come with MP1862A
• Coaxial cables that are of the same length
11. Connect the 1/2 Clock Output connector on the rear panel of
MP1862A and the Ext. Clock Input connector of MU183040B by
using the J1668A coaxial cable that comes with MP1862A.
