4.4 Setting Input Interface
4-17
4
Window Operations
[3] Select the measurement restart conditions.
This can be selected when the MP1862A and either the
MU183040A/B or the MU183041A/B are installed in the same main
frame, 4 ch Combination is executed, and the
DEMUX-ED Link
button is on.
Figure 4.4.1-4 Setting Screen for Measurement Restart Conditions
Table 4.4.1-5 Setting screen for measurement restart conditions
Input setting items Description
Measurement
Restart
Data
Threshold
Restarts measurement when changing Threshold voltage of this
module at check
Clock Delay
Restarts measurement when changing Delay of this module at
check
