Spectrum Analyzer Performance Verification 3-7 Input Related Spurious (IRS) Signals
Model MS20xxB MM PN: 10580-00303 Rev. D 3-15
55. Press the Shift key, press the Trace (5) key and then press the Trace A Operations submenu button.
56. Press the # of Averages submenu button.
57. Use the numeric keypad to enter 5, and then press the Enter key.
58. Wait until the Trace Count displays “5/5”.
59. Press the Marker main menu button and then Peak Search submenu button.
60. Record the Marker amplitude reading into the Measured Value column for 1219 MHz to 1221 MHz in
Table A-15 on page A-6 for MS2034B or Table A-40 on page A-19 for MS2035B in Appendix A.
61. Calculated the input related spurious level using the formula below:
Input Related Spurious dBc = Marker 1 Reading – Amplitude Reading of 1500 MHz
62. Record the calculated value into the Calculated IRS column for 1219 MHz to 1221 MHz in Table A-15 for
MS2034B or Table A-40 for MS2035B in Appendix A and verify that it is <
–52 dBc.
1690 MHz Input Related Spurious Check
63. Press the Freq main menu button and then the Start Freq submenu button.
64. Use the numeric keypad to enter 1689.5 and then press the MHz submenu button.
65. Press the Stop Freq submenu button.
66. Use the numeric keypad to enter 1691.5 and then press the MHz submenu button.
67. Press the Shift key, press the Trace (5) key and then press the Trace A Operations submenu button.
68. Press the # of Averages submenu button.
69. Use the numeric keypad to enter 5, and then press the Enter key.
70. Wait until the Trace Count displays “5/5”.
71. Press the Marker main menu button and then Peak Search submenu button.
72. Record the Marker amplitude reading into the Measured Value column for 1681.5 MHz to 1691.5 MHz in
Table A-15 for MS2034B or Table A-40 for MS2035B in Appendix A.
73. Calculated the input related spurious level using the formula below:
Input Related Spurious dBc = Marker 1 Reading – Amplitude Reading of 1500 MHz
74. Record the calculated value into the Calculated IRS column for 1689.5 MHz to 1691.5 MHz in Table A-15
for MS2034B or Table A-40 for MS2035B in Appendix A and verify that it is <
–52 dBc.
2822 MHz Input Related Spurious Check
75. Press the Freq main menu button and then the Start Freq submenu button.
76. Use the numeric keypad to enter 2821 and then press the MHz submenu button.
77. Press the Stop Freq submenu button.
78. Use the numeric keypad to enter 2823 and then press the MHz submenu button.
79. Press the BW main menu button and then the RBW submenu button.
80. Use the numeric keypad to enter 10 and then press the kHz submenu button.
81. Press the VBW submenu button.
82. Use the numeric keypad to enter 30 and then press the Hz submenu button.
83. Press the Shift key, press the Trace (5) key and then press the Trace A Operations submenu button.
84. Press the # of Averages submenu button.
85. Use the numeric keypad to enter 5, and then press the Enter key.
86. Wait until the Trace Count displays “5/5”.
