A7 Plus – OPERATOR'S MANUAL
Activation/deactivation of Peristaltic pump (if installed, only).
• To activate/deactivate peristaltic pump, simply touch the relevant icon
button:
Peristaltic pump not active.
Peristaltic pump active with
quantity of delivered saline
solution equal to 5.
pump activation is confirmed by the appearance of a relevant
box next to the value of delivered saline solution.
• Press icon buttons or to change the quantity of saline solution
delivered by the peristaltic pump.
value setting range: 1 to 5. The quantity of delivered solution
associated to the settable values is:
- value 1: approx.35 cc/min,
- value 2: approx.50 cc/min,
- value 3: approx.70 cc/min,
- value 4: approx.90 cc/min,
- value 5: approx.100 cc/min.
the quantity of saline solution delivered by the peristaltic pump
can also be edited when the instrument is active.
Removable cord.
The turbine features a removable cord to make cleaning operations
easier (see paragraph 5.).
Cleaning and care.
Refer to the specific instructions provided with the handpiece.
It is recommended to use Daily Oil (CEFLA s.c.) for lubrication.
Disinfection.
Instrument handpiece only: see paragraph 1.5.
Carefully read the operating instructions supplied with the
handpiece before attempting to sterilise.
• The turbine must never be started without attaching the
drill or fake drill.
• The drill release button must not be pressed down during
operation!
Friction between button and micromotor impeller
overheats the head and may cause burns.
• The patient’s internal tissues (tongue, cheeks, lips, etc.)
must be protected against contact with the button by
using suitable instruments (mirrors, etc.).
• The drills and various instruments attached to the
handpieces must comply with Biocompatibility Standard
ISO 10993.
