Anthos A7 Plus - ELECTRIC MICROMOTOR OPERATION

A7 Plus – OPERATOR'S MANUAL
44
EN
5.5. ELECTRIC MICROMOTOR
Coupling the handpieces and changing the drill.
Refer to the specific instructions provided with the micromotor and
various handpieces.
Use.
WARNING:
Also read the instructions for use of the various motors.
The instrument is supplied non-sterile.
• Operating times: work 5 min., rest 5 min.
• The cock ( f ), found near the instrument, is used to adjust spray water
quantity.
• The cock ( e ) adjusts the amount of air spray for all the instruments.
• Place the instrument in its work position.
NOTE:
instrument activation is highlighted by the relevant managing
screen appearing on the TOUCH DISPLAY.
• The main icon buttons available on the TOUCH DISPLAY are:
Increase of settable values.
Decrease of settable values.
Reduction ratio selection.
Reduction ratio selection.
Selection of turbine operating speed.
Selection of micromotor drill rotation direction.
Activation/deactivation of alarm signal.
Reduction ratio setting (see paragraph 5.5.4.).
Fiber optics on/off.
Activation/deactivation independent water supply (with
SANASPRAY system, only).
Activation and selection of the type of spray delivered by the
instrument.
Main screen controls recall.
Simplified menu display.
Activation/deactivation of
peristaltic pump (if installed,
only).
Micromotor operating mode selection.
Micromotor working programme selection.
• Use the foot control pedal to start the instrument (see paragraph 5.).
Fiber optic brightness adjustment.
• To adjust fiber optic brightness, touch icon button (for at least 2
seconds).
• Adjust brightness level by touching icon buttons or or scrolling
the bargraph with your finger.
NOTE:
value setting range: 1 to 16.
• To confirm the selected brightness, simply quit this sub-menu by
touching icon button .
NOTE:
the fiber optic switches off when the instrument (foot control
lever off) is not used for 30 seconds.
