APRILIA MXV 450 - Removing the Head Cover; Removing the Cylinder Head

Specific tooling
9100895 Water pump oil seal punch
Head and timing
Removing the head cover
•
Undo and remove the two screws (1)
and the two head cover stud bolts (2)
and collect the sealing O-rings.
•
Remove the head cover together with
the gasket.
Removing the cylinder head
NOTE
BEFORE REMOVING THE HEAD CHECK THAT THE CYLINDER PISTON ON WHICH YOU ARE
WORKING IS AT THE TDC IN COMBUSTION PHASE.
MXV 450 Engine
ENG - 103
