APRILIA MXV 450 - Assembling the Clutch

Checking the clutch hub
Check the clutch hub for damage and wear that
may result in clutch irregular operation. If neces-
sary, replace the hub.
Checking the springs
NOTE
THE FOLLOWING PROCEDURE IS VALID FOR ALL CLUTCH SPRINGS.
•
Check the springs for damage and, if
necessary, replace the them all togeth-
er.
•
Measure the clutch spring length when
unloaded; if necessary, replace the
springs all together.
Characteristic
Clutch spring length - minimum limit
45.1 mm (1.77 in)
Assembling the clutch
•
Fit the needle bearing and the spacer.
MXV 450 Engine
ENG - 99
