IF THE SPARE FUSE IS USED, REPLACE IT WITH ANOTH-
ER OF THE SAME TYPE IN THE CORRESPONDING FIT-
TING.
FUSE DISTRIBUTION
Specification Desc./Quantity
1 30A fuse Recharges the battery, if connected, and protects elec-
trical system against potential overcharges (there is only
one fuse; the second is a spare one).
Control unit
ECU
New bi-mapping type control unit with 48 pins,
specific for MXV and RXV MY2009.
For throttle minimum and maximum remapping
and self-learning, see details in the AXONE chap-
ter.
See also
Adjustable parameters screen page
•
Remove the fuel tank.
•
Remove the filter casing cover.
•
Disconnect the connector of the control
unit.
•
Remove the control unit.
Electrical system MXV 450
ELE SYS - 56
