APRILIA MXV 450 - Generator Side

•
Remove the gear locking pawl and re-
trieve the washer and the spring.
See also
Disassembling the
clutch
Splitting the
crankcase halves
Checking the gear selector
Check the stop lever for damage and wear and make sure the ball rotates freely.
If necessary, replace the parts.
Check the gear selector spring for damage and wear.
If necessary, replace the part.
Check the selector shaft and its teeth for damage and wear.
If necessary, replace the part.
Check the lever spring for damage and wear.
If necessary, replace the part.
•
Check the clearance of the washer and the riveted pin that passes through the plate. If it is
excessive, replace the pawl.
Reassembling the gear selector
•
To refit, lubricate and carry out the removal operations but in reverse order.
Generator side
Engine MXV 450
ENG - 90
