Removing the gear selector
•
Remove the clutch.
•
Remove the flange from the right
crankcase half.
•
Working from the clutch side, remove
the selector control shaft.
•
Undo and remove the two screws fixing
the selector sprocket wheel.
•
Remove the selector sprocket wheel
together with the plate.
•
Undo and remove the gear selector
drum fixing screws.
•
Lower the gear locking pawl lever and
slide off the lower part of the gear se-
lector drum.
