APRILIA MXV 450 - Checks and Inspections

5. Fuel pump
6. Voltage regulator
7. Generator
8. Water Temperature Sensor
9. Coil 2 (rear cil.) (fitted on the left)
10.Spark plug 2
11.Coil 1 (front cil.) (fitted on the right)
12.Spark plug 1
13.Intake air temperature sensor
14.Throttle sensor (TPS)
15.Injector 2 (rear cil.)
16.Injector 1 (front cil.)
17.Pick-up
18.Pick-up wire shielding
19.ECU
20.Engine stop
21.Map switch
22.Stepper
23.Pinion speed sensor (optional)
24.Capacitor (filter)
Cable colour
Ar Orange
Az Sky blue
B Blue
Bi White
G Yellow
Gr Grey
M Brown
N Black
R Red
V Green
Vi Purple
Ro Pink
Checks and inspections
Electrical system MXV 450
ELE SYS - 52
