Removing the fork legs
•
Undo and remove the two screws fixing
the front mudguard tie rod.
•
Undo and remove the four mudguard
fixing screws.
•
Remove the front mudguard.
•
Place the OPTIONAL front stand in the
hole of the fork lower plate.
•
Undo and remove both calliper fixing
screws.
•
Slide off the calliper.
CAUTION
THE SPEED SENSOR CABLE RUNS OUTSIDE THE CAL-
LIPER AND IS FITTED WITH PROTECTION.
•
Working on the left side, unscrew and
remove the front wheel axle fixing nut.
•
Working on both sides, loosen the screws on the wheel axle clamps.
